The latest model of the electric hearse from Melex. It is distinguished by a completely revised design. On the one hand, referring to the first Melex models, on the other hand emphasizing the modernity of applied solutions. The double A-frame suspension significantly improves comfort and maneuverability. It has a completely changed shape of the rear underlines which gives solidity to the whole structure and gives it a modern and original look. The double A-frame suspension suppresses the inequalities. The low/fast speed drive switch lets the vehicle smoothly moving with minimum speed. A high-quality special container is equipped with practical hooks for wreaths.

Hearse model
Vmax 25 kph Numărul de locuri 2

Echipament standard

  • 8 pcs of T-125 with capacity 240 Ah in discharging cycle 20h;
  • 5.0 kW AC motor;
  • battery charger on-board 48V;
  • wheels 195/55-10 or 20,5 x 8.0-10;
  • hydraulic drum brakes;
  • gear ratio 20:1;
  • top;
  • glass windshield with wiper and washer;
  • system of integrated indicators;
  • covered electric shifted platform for the coffin;
  • hooks for wreaths (6 pcs);
  • LED rear lamps;
  • LED daylights;
  • galvanized frame;
  • closed gloves compartment;
  • full light installation;
  • 12V socket in the dashboard;
  • 3-point seat belts;
  • mirrors;
  • wheels covers;
  • profiled seats grey or black.

Echipament adițional

  • lithium batteries with battery charger 2.3 kW;
  • lithium batteries with battery charger 7.2 kW;
  • installation for radio, loudspeakers, antenna;
  • radio with maintenance memory function;
  • system of refilling water in batteries 48V;
  • 8 pcs of batteries T-145 with a capacity of 260 Ah in discharging cycle 20h;
  • front tubular bumper;
  • forward drive buzzer;
  • bars on top protecting wreaths and anti-slide floor;
  • holder below the top to carry the cross;
  • compartment for line (below platform, in the rear side).

Color to be chosen of RAL palette.
